Technical
Specifications
| Technical Specifications |
| Tower Height |
80 metres (262ft) |
| Number of Passengers |
24 persons |
| Capacity |
700 persons/hr |
| Cycle Time |
2 minutes and 10 seconds |
| Power Required |
300kW/3~400V |
| Setup Time |
8 hours
*No crane required* |
| Ground Area |
23x20 metres |
| Number of Trailers |
5 |
| Brake System |
Permanent magnet from Intrasys |
| Seating System |
Gerstlauer |
| Testing Authority |
TUV Munich |
|
|
|
|
|
